VHJ Series
VHJ V-Type Mixer
Mirror-polished stainless steel V-type mixer for dry powder and granular blending with up to 99% uniformity.
- Mirror-polished inner and outer barrel walls
- No dead corners for complete discharge and cleaning
- Optional forced stirrer for fine powder or moist materials
- GMP-oriented design supports contamination control
Mixing Equipment99%
Mixing Uniformity
11
Standard Models
0.18-6.0 m³
Total Volume Range
Specifications
Technical parameters
| Model | Production Capacity (kg/time) | Vacuum Pump Model | Feed Time (min) | Mixing Time (min) | Total Volume (m³) | Stirring Speed (rpm) | Motor Power (kW) | Rotation Height (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|
| V-0.18 | 72 | W2 | 3-5 | 4-8 | 0.18 | 12 | 1.1 | 1580 | 280 |
| V-0.3 | 90 | W2 | 3-5 | 6-10 | 0.3 | 12 | 1.1 | 2160 | 320 |
| V-0.5 | 150 | W2 | 4-6 | 6-10 | 0.5 | 12 | 1.5 | 2360 | 550 |
| V-1.0 | 300 | W3 | 6-9 | 6-10 | 1.0 | 12 | 3 | 2600 | 950 |
| V-1.5 | 450 | W3 | 6-10 | 6-10 | 1.5 | 12 | 4 | 2800 | 1020 |
| V-2.0 | 600 | W3 | 8-13 | 6-10 | 2.0 | 12 | 5.5 | 2900 | 1600 |
| V-2.5 | 800 | W3 | 8-15 | 6-10 | 2.5 | 12 | 7.5 | 3000 | 2040 |
| V-3.0 | 900 | W4 | 8-12 | 8-12 | 3.0 | 10 | 7.5 | 3200 | 2300 |
| V-4.0 | 1200 | W4 | 10-15 | 8-12 | 4.0 | 10 | 11 | 4000 | 2800 |
| V-5.0 | 1500 | W4 | 15-20 | 8-12 | 5.0 | 10 | 15 | 4500 | 3250 |
| V-6 | 1800 | W4 | 18-25 | 8-12 | 6.0 | 10 | 18.5 | 5000 | 3850 |
Loading coefficient is 0.4-0.6; production capacity calculated at 0.5 loading coefficient and 0.8 material bulk density.
Related equipment
DSH SeriesMixing Equipment
DSH Double Screw Conical Mixer
Conical mixer using compound screw rotation and revolution for fast, uniform powder, granule, and liquid mixing.
View specifications
SZG SeriesDrying Equipment
SZG Conical Vacuum Dryer
Double-cone rotary vacuum dryer for low-temperature drying of heat-sensitive, oxidation-prone, and solvent-laden materials.
View specifications
ZLG SeriesDrying Equipment
ZLG Vibrating Fluidizing Dryer
Rectilinear vibrating fluidized bed dryer for uniform drying, cooling, and humidifying of powders and granules.
View specificationsEngineering Advantages
Built for demanding vacuum drying duty
Up to 99% Mixing Uniformity
Repeated splitting and recombining of the material stream at the V-barrel arms drives mixing uniformity as high as 99%.
No Dead Corners
The V-shaped barrel geometry eliminates dead corners, ensuring complete discharge and preventing product carryover between batches.
Easy Discharge and Cleaning
Mirror-polished interior surfaces and a dead-corner-free design make discharge and clean-down fast between product changeovers.
Optional Forced Stirrer
A forced stirrer attachment handles fine powders, cakes, and materials with some moisture content that plain rotation alone cannot disperse.
Mirror-Polished Stainless Steel
Inner and outer barrel walls are mirror-polished stainless steel, giving an attractive finish along with easy sanitation.
Low Rotation Height, Fast Cycles
A low rotation height keeps the mixer stable and easy to load, with typical mixing cycles completing in 6-25 minutes depending on model.
GMP-Oriented Design
No dead corners and full-surface polishing support contamination control practices required in GMP-oriented production environments.
Eleven Standard Sizes
Total volumes from 0.18 m³ to 6.0 m³ across eleven standard models make it straightforward to match capacity to batch size.
Working Principle
The vacuum rake drying cycle
- STEP 01
Charge Components
Two or more dry powder or granular materials are charged into the V-barrel through the top loading port.
- STEP 02
V-Barrel Rotation
The barrel rotates around its horizontal axis, repeatedly splitting the material stream at the two arms of the V.
- STEP 03
Convection & Diffusion Mixing
Each split-and-recombine cycle drives convection and diffusion across the full charge, rapidly evening out composition.
- STEP 04
Mix to Target Uniformity
Rotation continues for the model-specific mixing time, typically 6-25 minutes, until target uniformity is reached.
- STEP 05
Discharge Blend
The mirror-polished, dead-corner-free interior discharges completely through the outlet valve, leaving no residual product behind.
Structure Diagram
Inside the VHJ V-type mixer
Side view of the VHJ V-type mixer showing the two barrel arms joined at the rotation axis, the support frame, drive assembly, and discharge port at the base of the V.
Key Components
- V-Shaped Barrel
- Mirror-Polished Interior
- Discharge Port
Application Industries
Industries relying on the ZPG series
Pharmaceutical
- GMP-oriented dry powder blending
- Excipient and active ingredient mixing
- No dead corners limiting cross-contamination
Confirm documentation requirements with our engineers before specifying for regulated production.
Chemical & Metallurgical
- Powder and granule blending
- Metallurgical powder mixing
- Optional forced stirrer for moisture-bearing materials
Food & Feed Processing
- Food ingredient dry blending
- Feed powder and granule mixing
- Mirror-polished surfaces for easy sanitation
Why Choose Ruibo
Reasons processors specify Ruibo
Up to 99% Mixing Uniformity
The split-and-recombine action at the V-barrel arms consistently achieves mixing uniformity as high as 99% at a 0.8 volume loading coefficient.
No Dead Corners
A dead-corner-free interior geometry ensures complete discharge and prevents cross-batch contamination.
Mirror-Polished Construction
Fully mirror-polished stainless steel inner and outer walls give an attractive, easy-to-sanitize finish.
Optional Forced Stirrer
Add a forced stirrer to handle fine powders, cakes, or materials with some moisture content beyond plain rotational mixing.
GMP-Oriented Design
No dead corners and full-surface polishing align with contamination-control practices for GMP-oriented production.
Eleven Standard Sizes
Total volumes from 0.18 m³ to 6.0 m³ across eleven standard models make it straightforward to match capacity to production demand.
Materials Handled
